BenchCel User Guide : Introduction : Integration options for workstations
Integration options for workstations
About this topic
You can integrate Agilent devices with the BenchCel Microplate Handler to create a BenchCel Workstation. The BenchCel robot can move labware to and from these devices as specified by the protocol you create.
This topic lists some of the devices that can be integrated with the BenchCel Microplate Handler.
Agilent devices
The following figure shows an example of a BenchCel Workstation.
Figure Example of BenchCel Workstation: (1) computer, (2) Bravo Platform, (3) BenchCel with six stackers, and (4) Labware MiniHub

The following Agilent devices can be integrated with the BenchCel Microplate Handler.
:
Item
Device
Description
1
Bravo Platform
Dispenses liquids.
2
Labware MiniHub
Stores labware.
3
Microplate Labeler
Prints barcodes and applies the barcode labels to microplates.
4
Microplate Centrifuge with Automated Loader
Centrifuges microplates.
5
PlateLoc Thermal Microplate Sealer
Applies seal on microplates.
Related information

For more information about…
See…
BenchCel Microplate Handler features
Hardware overview
Safety information
Safety guidelines
Installation requirements
Installing BenchCel Microplate Handler
