Connecting the pendant directly to the BenchCel device
About this topic
If you are integrating the BenchCel Microplate Handler with devices that are not equipped with safety interlock circuitry, for example, the PlateLoc Sealer or the Microplate Labeler, use the procedure in this topic to connect the emergency-stop pendant.
Figure Emergency-stop pendant
 |
The pendant must be connected to close the safety interlock circuit. The circuit must be closed for the device to operate.
If the BenchCel Microplate Handler is integrated with devices that are equipped with safety interlock circuitry, such as the Bravo Platform, you connect the pendant through a main emergency-stop control, such as the Robot Disable Hub. See Connecting the pendant through the Robot Disable Hub.Procedure
To connect the pendant directly to the BenchCel device:
Connect the pendant cable to the pendant port on the back of the BenchCel device.
 |
Related information
For more information about… | See… |
|---|---|
Stopping in an emergency | |
Safety interlock circuit | |
Installing the BenchCel Microplate Handler |
